155~2.5Mb/s-MQ OPtics Co.,Ltd.

155~2.5Mb/s

The MQ Optics data rate range of 155M~ 2.67G SFP optical transceiver includes 155MB /s, 1.25Gb/s and 2.5Gb/s series. Support a variety of transmission distance from 500m to 120km, the series of optical transceiver use LC optical interface, with low power consumption, small size, high reliability, wide temperature range and other characteristics. It is mainly used in Ethernet/SDH/SONET/FC transmission environment.

Inquiry

Detail

P/N	Description	Data Rate	Reach	Tx	Rx	Output Power	Sensitivity
MQ-SFP-155-FR	SFP	155Mb/s	2Km	850nm VCSEL	PIN	-10.0~-3.0dBm	≦-24.0dBm
MQ-SFP-155-LR	SFP	155Mb/ss	20Km	1310nm FP	PIN	-15.0~-8.0dBm	돡-34.0dBm
MQ-SFP-155-ER	SFP	155Mb/s	40Km	1310nm FP	PIN	-5.0~0dBm	≦-34.0dBm
MQ-SFP-155-ZR	SFP	155Mb/s	80Km	1550nm DFB	PIN	-5.0~0dBm	≦-34.0dBm
MQ-SFP-1G-SR	SFP	1.25Gb/s	500m	850nm VCSEL	PIN	-9.0~-3.0dBm	≦-17.0dBm
MQ-SFP-1G-FR	SFP	1.25Gb/s	2Km	1310nm FP	PIN	-9.0~-3.0dBm	≦-17.0dBm
MQ-SFP-1G-LR	SFP	1.25Gb/s	20Km	1310nm FP	PIN	-9.0~-3.0dBm	≦-23.0dBm
MQ-SFP-1G-ER	SFP	1.25Gb/s	40Km	1310nm DFB	PIN	-2.0~+3.0dBm	≦-24.0dBm
MQ-SFP-1G-ER15	SFP	1.25Gb/s	40Km	1550nm DFB	PIN	-5.0~0dBm	≦-24.0dBm
MQ-SFP-1G-ZR	SFP	1.25Gb/s	80Km	1550nm DFB	PIN	-2.0~+3.0dBm	≦-24.0dBm
MQ-SFP-1G-ZR120	SFP	1.25Gb/s	120Km	1550nm DFB	APD	0~+5.0dBm	≦-32.0dBm
MQ-SFP-2G-SR	SFP	2.5Gb/s	300m	850nm VCSEL	PIN	-10.0~-3.0dBm	≦-17.0dBm
MQ-SFP-2G-FR	SFP	2.5Gb/s	2Km	1310nm FP	PIN	-10.0~-3.0dBm	≦-18.0dBm
MQ-SFP-2G-LR	SFP	2.5Gb/s	20Km	1310nm DFB	PIN	-5.0~0dBm	≦-18.0dBm
MQ-SFP-2G-ER	SFP	2.5Gb/s	40Km	1550nm DFB	PIN	-2.0~+3.0dBm	≦-18.0dBm
MQ-SFP-2G-ZR	SFP	2.5Gb/s	80Km	1550nm DFB	APD	-2.0~+3.0dBm	≦-28.0dBm
MQ-SFP-2G-ZR120	SFP	2.5Gb/s	120Km	1550nm DFB	APD	-1.0~+5.0dBm	≦-31.0dBm
